Including magnetizing equipment, magnetizing power supply, magnetizing coil, chiller, flux meter (optional), surface magnetic detection software, Gauss meter
1. Wide range of rotor compatibility
2. Simple operation, high automation length, and anti- misoperation function
3. Surface magnetic detection software processes and analyzes data, and the detection data can be uploaded
4. It can detect whether the magnetization is saturated, whether the magnet is missing, and whether the polarity is correct.
5. Convenient model change + model change trolley (optional)
6. The assembly line passes through the equipment, and the assembly line pallet incoming material method
7. The magnetization detection coil can be raised or lowered to communicate with the magnetization power supply, and the device status can be monitored in real time.
8. Can embed magnetic flux detection, magnetization + magnetic flux integrated into one
project | Technical Parameters | Remark |
Input Power | AC220V±5% 50/60Hz | |
Input Current | <20A | |
Rated Power | <5KW | |
Equipment noise | ≤75dB | Except for the moment of magnetization |
Device size | Length, width and height: 1800*1300*3000mm | Including electrical cabinet |
Equipment weight | ≤2000kg | |
Changeover time | ≤30min | Tooling + coil |
1 | Ambient temperature: 0℃~40℃; |
2 | Ambient humidity < 80% (no condensation); |
3 | Plant height (column top height): 3.5m; |
4 | Ground load: >2 tons/㎡; |
5 | Factory equipment transportation door size: width 1500 × height 2500mm; |
6 | Gas source: air pressure 0.4～0.6Mpa, flow rate 0.3m 3 /min; |
7 | No dust, no oil smoke, no salt, no dripping water; |
8 | Avoid direct sunlight; |
9 | No flammable, corrosive liquids and gases; |
10 | No shock and high-frequency vibration; |
11 | Use location: Open workshop environment. |
